Playing with SharePoint Rich Text Editor (RTE)

At my current project we needed to add a text highlight function button to the Rich Text Editors (RTE) ribbon, so when the user click on the button a selected text in the RTE, is wrapped with a predetermined HTML tag, indicating the text has been highlighted. Like <span css=”highlight”>the selected text</span>

The thing we need is:

1) The button in the ribbon, only showed when we are in the context of the RTE

2) The JavaScript snippet the will interact with the RTE

3) A feature the adds the ribbon button and the JavaScript to the page

The button is added to the style group like this:

<?xml version="1.0" encoding="utf-8"?>
<Elements xmlns="http://schemas.microsoft.com/sharepoint/">
  <CustomAction
   Id="Ribbon.Demo.HighlightText"
   Location="CommandUI.Ribbon"
   Title="Insert Tooltips">
    <CommandUIExtension>
      <CommandUIDefinitions>
        <CommandUIDefinition Location="Ribbon.EditingTools.CPEditTab.Styles.Controls._children">
          <Button
           Id="Ribbon.Demo.HighlightText.Button"
           Sequence="12"
           LabelText="High light text"
           Alt="High light text"
           TemplateAlias="o1"
           Image32by32="/_layouts/RTE.Demo/images/highlight32.png"
           Command="Ribbon.Demo.HighlightText.Command"
           ToolTipTitle="High light text"
      />
        </CommandUIDefinition>
      </CommandUIDefinitions>
      <CommandUIHandlers>
        <CommandUIHandler
         Command="Ribbon.Demo.HighlightText.Command"
         CommandAction="javascript:HighLightText();"
         EnabledScript="true" />
      </CommandUIHandlers>
    </CommandUIExtension>
  </CustomAction>
</Elements>

The JavaScript snippet looks like this:

function HighLightText() {
    var rng = RTE.Cursor.get_range().$3_0;
    var selectedText = RTE.Cursor.s_range.get_text();
    RTE.Cursor.get_range().deleteContent();
    var d = rng.ownerDocument;
    var a = d.createElement("span");
    a.innerHTML = selectedText;
    a.setAttribute("class", "highlight");
    SP.UI.UIUtility.insertAfter(a, rng);
}

Download the full project here
